Kitchen Design · 6 min read

600 / 700 / 900 series: depth, capacity or both?

Industrial kitchen series (60, 70, 90 cm depth) — which fits which kitchen? Line planning, GN compatibility and decision matrix.

Caccia Pro Mühendislik EkibiMay 8, 2026

The numbers aren't just catalog decoration

Industrial-kitchen catalogs say "700 series range", "900 series stove", "600 series counter". The number is equipment depth — the front-to-back length in mm.

  • 600 series: 600 mm (60 cm) depth
  • 700 series: 700 mm (70 cm) depth
  • 900 series: 900 mm (90 cm) depth

Looks like a small delta; in practice it changes how the cook line works.

Why depth matters

Line depth dictates three things:

  1. Usable work area — reach distance between chef and equipment
  2. GN tray compatibility — whether standard 1/1 GN trays fit lengthwise/widthwise
  3. Side-by-side alignment — continuous, flush visual and functional line

600 series: boutique, café, light-duty

600 mm is the most compact. Mostly used in:

  • Small cafés, breakfast venues
  • Open-kitchen boutique restaurants
  • Catering prep units

GN compatibility is limited — 1/1 GN (530 × 325 mm) fits, but only sideways; rarely room for a second row. No space for a second row GN in the cook zone.

Advantage: breathing room in tight kitchens. Field example — a 28 m² boutique bistro built on 600 series would be impossible to run with the same menu on 700.

700 series: the most common pro standard

700 mm is what we see in about 70% of Turkish restaurant kitchens. Reasons:

  • 1/1 GN sits upright comfortably, with room for a 1/3 GN beside it
  • Visual alignment with standard 60 cm counters
  • Under-hood 600 mm equipment + 100 mm service rear is ergonomic

Fits well for:

  • À la carte mid-scale restaurants
  • Pizzeria + grill mixed menus
  • Hotel breakfast + lobby bar kitchens
  • Single-shift catering

900 series: heavy-duty, high capacity

900 mm is industrial-grade. We recommend it for:

  • Hotel main kitchens (banquet + à la carte)
  • Hospital, factory, university canteens
  • High-volume QSR chains
  • Banquet / catering commissaries

Advantages:

  • Top depth accommodates two GN rows side by side (1/1 + 1/3)
  • Drawer / oven integration below the cook zone is possible
  • Heavier body + heavier burners → 300+ shifts/year durability
  • A continuous run of plate + range + fryer creates a visual architectural line
900 series isn't equipment, it's infrastructure. Once chosen, the hood, floor drain and gas/electrical panel are all designed around that depth.

GN tray compatibility detail

Industrial kitchens dimension everything around Gastronorm (GN). 1/1 GN = 530 × 325 mm. Placement in the cook zone:

  • 600 series: 1/1 GN only sideways (530 mm running with the line)
  • 700 series: 1/1 GN upright (325 mm depth) sits cleanly; 1/2 GN adds beside
  • 900 series: 1/1 GN upright + rear 1/3 GN together; two-row mise en place

That delta translates to mise en place capacity during peak — how many covers' worth of prep sits within the chef's reach.

Mixing series in one line

We almost never mix series. A single kitchen should hold one depth:

  • Side-by-side alignment isn't aesthetic, it's functional — chef gets the same reach at every station
  • Hood is a single run; mixed depth requires extra plenum
  • Drawers, base cabinets, base ovens are only compatible within one series

For very large island-design kitchens, an island at 900 + wall line at 700 is possible — but that's an exception, not the rule.

Decision matrix

Kitchen TypeRecommendation
Café, 30-50 covers, breakfast600 series
Bistro, 50-80 covers, à la carte700 series
Restaurant, 80-150 covers, mixed700 series
Hotel breakfast + lobby bar700 series
Hotel main kitchen + banquet900 series
Hospital / canteen / catering900 series
QSR chain commissary900 series

Conclusion

600 / 700 / 900 means depth — but depth is really the sum of capacity, GN compatibility and line ergonomics. Share kitchen m², menu mix and peak covers; we'll spec the right series after sketching the layout.
